Veterinary Patient Warming
Temperature Management Controllers
HotDog Veterinary Temperature Management Controllers deliver low-voltage electricity to Warming Blankets and Mattresses, where it is converted into safe, consistent heat by our patented semi-conductive polymer fabric. Designed with veterinarians in mind, the controllers provide simple touchscreen operation, built-in training tools, and safety features that ensure effective and reliable warming in every procedure. Whether you’re using a Blanket or our new 2-in-1 Warming + Grounding Mattress, the system adapts to your workflow with ease. Every Controller is backed by a full 1-year warranty, giving your practice confidence in both performance and durability.
WC77V
Temperature Management Controller Multiport
The WC77V Veterinary Controller is a versatile multi-port system designed to support advanced warming needs in veterinary care. With the capacity to power up to four Warming Blankets and one Warming Mattress, including the HotDog 2-in-1 Warming + Grounding Mattress, it provides flexibility and efficiency for a wide range of procedures.
- Compatible with all Veterinary Warming Blankets
- Compatible with HotDog Warming + Grounding Mattresses
- Powers up to 4 Blankets and 1 Mattress simultaneously
- Touchscreen user interface for streamlined control
- Integrated training slide shows
- Alarm error codes displayed for troubleshooting
- Adjustable settings for volume, brightness, and preferences
- Temperature display options: °F or °C
- Two independent over-temperature alarms for safety
- IV pole mount clamp included
- Cable retention loop/strap for improved cable management
- Universal VESA bracket mount
- Lightweight – 11½” high, 8.30 lbs.
- Quiet operation
WC71V
Temperature Management Controller Single Port
The WC71V Veterinary Controller is a compact, single-port unit designed to deliver reliable warming for one patient at a time. Built with veterinary practices in mind, it combines ease of use with essential safety features, ensuring consistent performance for everyday clinical use.
- Compatible with all Veterinary Warming Blankets
- Powers 1 Blanket to warm a single patient
- Touchscreen user interface for easy operation
- Integrated training slide shows
- Alarm error codes displayed for troubleshooting
- Adjustable settings for volume, brightness, and preferences
- Temperature display options: °F or °C
- Two independent over-temperature alarms for safety
- IV pole mount clamp included
- Cable retention loop/strap for improved cable management
- Universal VESA bracket mount
- Lightweight – 11½” high, 6.35 lbs.
- Quiet operation
WC7XV Specifications
| Dimensions | 11” high x 7” deep x 8.75” wide (28 cm H x 17.8 cm D x 22.2 cm W) |
| Weight | 6.4 – 8.3 lbs (2.9 – 3.75 kg) excluding clamp |
| Mounting | Can be placed on a horizontal flat surface (i.e. table top), clamped to an IV pole, or hung using a VESA mount of either FDMI MIS-C (35 × 75 mm) or FDMI MIS-D (75 × 75 mm) specifications |
| Temperature Control | Micro-processor |
| Blanket Operating Temperatures | Blanket Ports A adjustable in 1oC increments 37° to 43° ± 1.0°C (98.6° to 109.4° ± 1.8°F) |
| Mattress Operating Temperature | Mattress Port M adjustable in 1oC increments 35° to 40° ± 1.0°C (95° to 104° ± 1.8°F) |
| Device Ratings | Input: 100-240 VAC, 50/60 Hz, 460VA–970VA Output A, B, C, D: 48 VDC, 480 VA Max each Output M: 48 VDC, 336 VA Max |
| Leakage Current | Meets UL 60601-1 and IEC 60601-1 requirements for Class I, Type BF equipment. |
| Power Consumption | 850W maximum (during warm-up with all ports occupied) |
| Certifications | IEC 60601-1; EN 60601-1-2; UL 60601-1; CAN/CSA-C22.2, No. 601.1, EN 55011 |
Warming Blankets
Blanket Features:
- Reusable – environmentally friendly
- Heavy-weight polyurethane outer shell resists punctures
- Easy to clean
- Warms up in just a few minutes
- Flexible – use over, under or around the patient
- Includes adjustable straps that can be used to maximize contact and heat transfer
- 1 year warranty
Blanket Sizes and Uses
V101 – Extra Small
10″ x 12″ (25.4cm x 30.5cm)
Very Small Animals like Mice and Rats in Research
V102 – Small
10″ x 23″ (25.4cm x 58.4cm)
Exotics or Pocket Pets
V103 – Medium
16″ x 22″ (40.6cm x 55.9cm)
Average-sized Cats or Small Dogs
V104 – Large
22″ x 31″ (55.9cm x 78.7cm)
Average-sized Dogs
V106 – Extra-Large
27″ x 47″ (68.6cm x 119.4cm)
Large Dogs
Select the blanket size that is the best fit for your patient
HotDog Vs. Competition
| HotDog | Hot Air | Hot Water | |
|---|---|---|---|
| Effective Warming |  | | |
| Even Heat Distribution | | ||
| Low Ongoing Costs | | ||
| Durable Waterproof Blankets | | ||
| Easy to Clean | | ||
| Won't Dry EKG Lead or Mucous Membranes | | |
|
| Maintenance-free Controller | | ||
| Quiet Operation | | |
|
| Fast Warm-up Time | | | |
| Small and Light for Easy of Use | | ||
| No Blowing Air on Surgical Site | | |
|
| No Hot Air Blowing on You | | |
|
| Cable Easily Fits through Cage Slats | | |
|
| Environmentally Friendly | | |
|
| Energy Efficient | Average 100 Watts | Average 900 Watts | Average 800 Watts |
Great for surgery, x-rays, dental procedures and recovery.
HotDog Veterinary Patient Warming is an improvement over infrared heat lamps, heated O.R. tables, microwave disks, heated water bottles, Forced-Air or water systems for treatment of anesthesia induced hypothermia.
